Ejector Blades

What you needStep 1 of 2

If your uploaded files contain all required dimensions and tolerances you can skip the step below.

Upload a CAD File Or Drawing

Click here to upload a zipped file or an image You can upload up to 10 files.

Blades


EJB-EHN

Material

H-13

Surface Hardness

˜68 HRC (Nitrided)

Inside Bearing Hardness

˜44 HRC

Standard Tolerances

(D) 0/-0.1

(H) +.000/-.02

(K) +.000/-.05

(L) +2/0

(S) -1/-2

(W) 0/-.015

(T) 0/-.015

EJB-ELH

Material

1.2210 (AISI L2 Type) Steel

Surface Hardness

˜60 HRC

Core Hardness

˜60 HRC

Standard Tolerances

(D) 0/-0.1

(H) +.000/-.02

(K) +.000/-.05

(L) +2/0

(S) -1/-2

(W) 0/-.015

(T) 0/-.015

EJP-IMH

Material

M2 / 1.3343 / SKH51

Surface Hardness

58-62 HRC

Core Hardness

58-62 HRC

Standard Tolerances

(D) -0.0003/-0.0008

(H) +0/-0.010

(K) +0/-0.002

(L) +.12/-.00

(S) NA

(W) +0/-0.0003

(T) +0/-0.0003

Blade Length - +.06/-0

JEB

Material

SKS21

Surface Hardness

58 HRC+/-2 (Nitrided)

Core Hardness

˜30 HRC

Standard Tolerances

(D) 2-2.5

-.008/-.018

(D) 3.5-5

-.010/-.020

(D) 6-7

-.015/-.025

(D) 10-12

-.020/-.030

(H) -0.05/-0.15

(K) 0/-0.03

(L) +2/0

(S) -1/-2

(W) 0/-0.01

(T) +0/-0.01

DIMENSIONS
